Master Patch Cord
If your application requires precise and repeatable testing, Measurement or Reference Patch cord is required. Exceeding Telcordia’s end-face geometry standards, our reference patchcord has insertion loss as low as 0.15dB while return loss greater than 55dB. Every reference and measurement jumper will have a unique identification number. Individual interferometer report which includes all measured figures of end-face geometric parameter, insertion loss and return loss, will be attached to each measurement or reference jumper. Please contact us for details.
Features: Geometric property exceeds Telcordia GR-326-CC-CORE Insertion Loss < 0.15dB Return Loss >55dB Comes with DORC quality report Available with FC,SC,ST,LC,MU connectors |
![]() |
Specifications:
Cable type | Singlemode |
polish | UPC |
Insertion loss(dB) | < 0.15 |
Return loss(dB) | >55 |
Ordering Information:
![](../../images/products image/patch cord image/2.png)
Example: S1-F2-F2-01-0050
Patch Cord:
Singlemode First End FC/UPC
Second End FC/UPC
Simplex 3.0mm
Length 5M
